Modifying Water Hydrant Handles
To Make Them Safer
Long Description for the MK-6 Hydrant's Parts List
| Item | Part# | Description |
|---|---|---|
| 1. | 41025 | Manual Close Handle |
| 2. | 41201 | Set Screw |
| 3. | 41202 | Handle Pin |
| 4. | 41029 | Packing Nut |
| 5. | 41014 | O-Ring |
| 6. | 41067 | Bonnet Nut |
| 7. | 41082 | 1-½ x 1-¼ Reducing Pipe Bushing (U150) |
| 8. | 41094 | 2 x 1-¼ Reducing Pipe Bushing (U200) |
| 9. | 41084 | 1-½-Inch NPT Tee (U150) |
| 10. | 41095 | 2-Inch NPT Tee (U200) |
| 11. | -- | 1-½-Inch Galv. Pipe (U150) |
| 12. | -- | 2-Inch Galv. Pipe (U200) |
| 13. | 41086 | 1-½-Inch Valve Body (U150) |
| 14. | 41097 | 2-Inch Valve Body (U200) |
| 15. | 41632 | Stem |
| 16. | 41102 | Spring |
| 17. | 41625 | ¼-Inch NPSM Locknut |
| 18. | 41631 | Coupling |
| 19. | U150 Operating Rod (Manual Close Handle) | |
| 42127 | 1 Ft Bury (37-9/16-Inch Long) | |
| 42113 | 2 Ft Bury (49-9/16-Inch Long) | |
| 42114 | 3 Ft Bury (61-9/16-Inch Long) | |
| 42115 | 4 Ft Bury (73-9/16-Inch Long) | |
| 42116 | 5 Ft Bury (85-9/16-Inch Long) | |
| 42117 | 6 Ft Bury (97-9/16-Inch Long) | |
| 42118 | 7 Ft Bury (109-9/16-Inch Long) | |
| 20. | U200 Operating Rod (Manual Close Handle) | |
| 42177 | 1 Ft Bury (37-13/16-Inch Long) | |
| 42178 | 2 Ft Bury (49-13/16-Inch Long) | |
| 42179 | 3 Ft Bury (61-13/16-Inch Long) | |
| 42180 | 4 Ft Bury (73-13/16-Inch Long) | |
| 42181 | 5 Ft Bury (85-13/16-Inch Long) | |
| 42182 | 6 Ft Bury (97-13/16-Inch Long) | |
| 42183 | 7 Ft Bury (109-13/16-Inch Long) | |
| 21. | 41013 | Swivel Screw |
| 22. | 41012 | Swivel Coupling |
| 23. | 41078 | Plunger (U150) |
| 24. | 41089 | Plunger (U200) |
| 25. | 41079 | O-Ring (2 Required) (U150) |
| 26. | 41090 | O-Ring (2 Required) (U200) |
| 27. | 41080 | Rubber Seat Washer (U150) |
| 28. | 41091 | Rubber Seat Washer (U200) |
| 29. | 41081 | Brass Washer (U150) |
| 30. | 41092 | Brass Washer (U200) |
| 31. | 41059 | Screw |
| Note: MK-6 Plunger Repain Parts. Call For Individual Pricing | ||
